The CSI-100K-T4001 is a powerful and efficient string inverter tailored for large commercial and utility-scale solar power systems. Designed to deliver reliable, high-efficiency performance, it integrates advanced MPPT technology and smart monitoring capabilities to maximize energy harvest and system uptime.
(CSI-100K-T4001)
Canadian Solar 100kW Three-Phase String Inverter – Efficient Power for Commercial Solar Systems
The Canadian Solar 100kW Three-Phase String Inverter is a strong and efficient solution for commercial and industrial solar installations. It helps businesses get more energy from their solar panels while keeping power conversion stable and reliable.
To start, this 100kW three-phase inverter delivers high efficiency, so you can convert more solar energy into usable electricity. Because of this, your system performs better throughout the day. In turn, this helps lower electricity costs and improves your overall return on investment.
In addition, the inverter includes multiple MPPT trackers. This means it can manage different panel strings more effectively, even when panels are installed at different angles or experience partial shading. As a result, your system maintains consistent energy output in changing conditions.
Moreover, the inverter is built for tough environments. It runs reliably in commercial and industrial settings, which makes it a dependable choice for long-term use. Its durable design ensures stable performance over time.
Another advantage is its smart monitoring capability. You can easily track system performance in real time, which helps you stay in control of energy production and quickly address any issues. This leads to better system uptime and easier maintenance.
Key Features:
- High Power Output: Rated at 100 kW with the ability to handle fluctuating loads and variable solar input efficiently.
- Multiple MPPT Channels: Equipped with 8 independent MPPTs for optimized energy capture and greater system design flexibility.
- Superior Efficiency: Maximum efficiency up to approximately 98.7%, ensuring minimal energy loss.
- Robust Design: IP66-rated enclosure offers strong protection against dust and water, suitable for harsh outdoor conditions.
- Advanced Safety Features: Includes comprehensive protections such as anti-islanding, DC reverse polarity, surge protection, and rapid shutdown compliance.
- Smart Connectivity: Supports RS485 and optional Wi-Fi or 4G communication for remote monitoring and control.
- Wide Operating Range: Supports high input voltages (up to 1100 V DC) and a wide operating temperature range to accommodate diverse climates.
Specifications Snapshot:
- Rated AC Power: 100 kW
- Max Efficiency: ~98.7%
- MPPT Inputs: 8 independent MPPTs
- Input Voltage Range: Up to 1100 V DC
- Output Voltage: 380/400 VAC, three-phase
- Protection Rating: IP66
- Operating Temperature: -30°C to +60°C
- Dimensions & Weight: Compact and durable design suited for commercial rooftops and ground mounts
