LUNA2000 – 200KTL Series Smart PCS

The Huawei LUNA2000-200KTL Series Smart PCS (Power Conversion System) is a high-capacity, bi-directional inverter designed to convert and control energy flow between DC battery storage systems and the AC grid. Engineered for integration with the LUNA2000 Smart String ESS, it provides seamless support for grid-tied applications, off-grid backup, and energy shifting scenarios.

With a rated power output of 200 kW, this PCS delivers high efficiency (≥98.5%), full reactive power capability, and supports advanced grid functions such as black start, anti-islanding, and grid-forming control. It can operate independently or in parallel with other PCS units for scalable deployments in commercial, industrial, and utility energy storage systems.

Featuring smart air cooling, IP66 protection, and a rugged outdoor-rated design, the LUNA2000-200KTL PCS performs reliably in harsh environments. It connects with the FusionSolar platform for intelligent monitoring and management, supporting Modbus TCP and IEC 104 protocols.

Add to quote

FusionSolar Utility Smart String ESS Solution Datasheet-20250331 [8-9]

LUNA2000-200KTL-H1_Smart_Power_Control_System_User_Manual_2024-04-25_V09_EN

The LUNA2000-200KTL Series Smart PCS (Power Conversion System) is a high-capacity, intelligent solution designed for large-scale solar and energy storage applications. It delivers efficient bidirectional power conversion, enabling seamless energy flow between the grid, battery storage systems, and renewable energy sources.

Engineered for commercial and industrial environments, the LUNA2000-200KTL Series ensures high conversion efficiency, stable operation, and advanced energy management capabilities. It plays a critical role in optimizing energy usage, supporting peak shaving, load balancing, and improved grid stability.

With integrated smart control technology, the system enables real-time monitoring, remote diagnostics, and intelligent power regulation. This ensures maximum system visibility and helps operators maintain optimal performance while reducing operational costs and downtime.

The robust design of the LUNA2000-200KTL Series ensures reliable performance even under demanding conditions. Its modular architecture supports flexible deployment and easy integration into existing energy storage or solar infrastructure.

Safety is a key priority, with built-in protection features that safeguard against electrical faults, overheating, and abnormal operating conditions, ensuring secure and stable operation at all times.

The LUNA2000-200KTL Series Smart PCS is a powerful and reliable solution for modern energy systems, delivering intelligent control, high efficiency, and seamless integration for utility-scale energy storage applications.

Key Features & Specifications

Feature	Specification
Model	LUNA2000-200KTL
Rated AC Output Power	200 kW
Max. Apparent Power	220 kVA
AC Voltage Range	400 / 480 V (3-phase)
Rated AC Current	289.1 A @400 V / 240.5 A @480 V
THDi	≤1.5%
Power Factor	Adjustable (–1 to +1)
DC Voltage Range	1,000 V – 1,350 V
Max. DC Voltage	1,500 V
Rated DC Voltage	1,200 V
Max. DC Current	200 A
Conversion Efficiency	≥98.5% (Max.)
Black Start Support	Yes
Communication Interfaces	Ethernet / SFP
Protocols Supported	Modbus TCP, IEC 104
Monitoring Platform	FusionSolar Smart PV Management

Design & Durability

Parameter	Value
Cooling Method	Smart air cooling
IP Rating	IP66
Operating Temperature	–30°C to +55°C
Max. Altitude	4,000 m
Noise Level	≤65 dB(A)
Dimensions (W × H × D)	Approx. standard PCS cabinet size
Weight	Varies by configuration (~<300 kg typical)
